MODIS/Terra+Aqua Land Cover Type Yearly L3 Global 500m SIN Grid V061

The Terra and Aqua combined Moderate Resolution Imaging Spectroradiometer (MODIS) Land Cover Climate Modeling Grid (CMG) (MCD12C1) Version 6.1 data product provides a spatially aggregated and reprojected version of the tiled MCD12Q1 Version 6.1 data product. Maps of the International Geosphere-Biosphere Programme (IGBP), University of Maryland (UMD), and Leaf Area Index (LAI) classification schemes are provided at yearly intervals at 0.05 degree (5,600 meter) spatial resolution for the entire globe. Additionally, sub-pixel proportions of each land cover class in each 0.05 degree pixel is provided along with the aggregated quality assessment information for each of the three land classification schemes. Provided in each MCD12C1 Version 6.1 Hierarchical Data Format 4 (HDF4) file are layers for Majority Land Cover Type 1-3, Majority Land Cover Type 1-3 Assessment, and Majority Land Cover Type 1-3 Percent. Known Issues * Known issues are described in Section 2.2 of the User Guide. * For complete information about known issues please refer to the MODIS/VIIRS Land Quality Assessment website.

The Terra and Aqua combined Moderate Resolution Imaging Spectroradiometer (MODIS) Land Cover Dynamics (MCD12Q2) Version 6.1 data product provides global land surface phenology metrics at yearly intervals. The MCD12Q2 Version 6.1 data product is derived from time series of the 2-band Enhanced Vegetation Index (EVI2) calculated from MODIS Nadir Bidirectional Reflectance Distribution Function (BRDF)-Adjusted Reflectance (NBAR). Vegetation phenology metrics at 500 meter spatial resolution are identified for up to two detected growing cycles per year. For pixels with more than two valid vegetation cycles, the data represent the two cycles with the largest NBAR-EVI2 amplitudes. Provided in each MCD12Q2 Version 6.1 Hierarchical Data Format 4 (HDF4) file are layers for the total number of vegetation cycles detected for the product year, the onset of greenness, greenup midpoint, maturity, peak greenness, senescence, greendown midpoint, dormancy, EVI2 minimum, EVI2 amplitude, integrated EVI2 over a vegetation cycle, as well as overall and phenology metric-specific quality information. SDS layers may be multi-dimensional with up to two valid vegetation cycles. For areas where the NBAR-EVI2 values are missing due to cloud cover or other reasons, the data gaps are filled with good quality NBAR-EVI2 values from the year directly preceding or following the product year. Known Issues * Known issues are described in Section 3.2 of the User Guide. * For complete information about known issues please refer to the MODIS/VIIRS Land Quality Assessment website.

The Aqua Moderate Resolution Imaging Spectroradiometer (MODIS) Land Surface Temperature/Emissivity Monthly (MYD11B3) Version 6.1 product provides average monthly per pixel Land Surface Temperature and Emissivity (LST&E) in a 1,200 by 1,200 kilometer (km) tile with a pixel size of 5,600 meters (m). Each LST&E pixel value in the MYD11B3 is a simple average of all the corresponding values from the MYD11B1 collected during the month period. Each MYD11B3 granule consists of 19 layers including daytime and nighttime layers for LSTs, quality control assessments, observation times, view zenith angles, and number of clear sky observations along with percentage of land in the tile and emissivities from bands 20, 22, 23, 29, 31, and 32. Unique to the MYD11B products are additional day and night LST layers generated from band 31 of the corresponding 1 km MYD11_L2 swath product aggregated to the 6 km grid. Known Issues * For complete information about known issues please refer to the MODIS/VIIRS Land Quality Assessment website.

The MCD19A1 Version 6.1 data product is a Moderate Resolution Imaging Spectroradiometer (MODIS) Terra and Aqua combined Land Surface Bidirectional Reflectance Factor (BRF) gridded Level 2 product produced daily at 500 meter (m) and 1 kilometer (km) pixel resolutions. The MCD19A1 product is corrected for atmospheric gases and aerosols using a Multi-Angle Implementation of Atmospheric Correction (MAIAC) algorithm that is based on a time series analysis and a combination of pixel- and image-based processing. The MODIS MAIAC Land Surface BRF products provide an estimate of the surface spectral reflectance as it would be measured at ground-level in the absence of atmospheric scattering or absorption. The MCD19A1 MAIAC Surface Reflectance data product includes 31 Science Dataset (SDS) layers: surface reflectance for bands 1-12, BRF uncertainty for bands 1-2, Quality Assessment (QA) bits at 1 km, surface reflectance for bands 1-7 at 500 m, cosine of solar zenith angle, cosine of view zenith angle, relative azimuth angle, scattering angle, solar azimuth angle, view azimuth angle, glint angle, RossThick/Li-Sparse (RTLS) volumetric kernel, and RTLS geometric kernel at 5 km. A low-resolution browse image is also included showing surface reflectance band combination 1, 4, 3 created using a composite of all available orbits. Each SDS layer within each MCD19A1 Hierarchical Data Format 4 (HDF4) file contains a third dimension that represents the number of orbit overpasses. This factor could affect the total number of bands for each SDS layer. Known Issues * Known issues are described in Section 6 of the User Guide. * For complete information about known issues please refer to the MODIS/VIIRS Land Quality Assessment website.

The Terra Moderate Resolution Imaging Spectroradiometer (MODIS) Land Water Mask (MOD44W) Version 6.1 data product provides a global map of surface water at 250 meter (m) spatial resolution. The data are available annually from 2000 to present. MOD44W Version 6.1 is derived using a decision tree classifier trained with MODIS data and validated with the Version 5 MOD44W data product. A series of masks are applied to address known issues caused by terrain shadow, burn scars, cloudiness, or ice cover in oceans. Version 6.1 is the generation of a time series rather than a simple static representation of water, given that water bodies fluctuate in size and location over time due to both natural and anthropogenic causes. Provided in each MOD44W Version 6.1 Hierarchical Data Format 4 (HDF4) file are layers for land water mask and water body classification. A quality assurance (QA) layer provides users with information on the determination of water. The new seven class water classification layer provides values for shallow ocean, land, shoreline, inland water, ephemeral water, deep inland water, moderate ocean, deep ocean, and a classification deemed to fall outside of the projection. Known Issues * The seven_class SDS layer legend for classes 4 and 5 are incorrectly listed as Deep Inland Water and Ephemeral Water in the data for the entire mission period. Users are requested to follow the legend provided in the User Guide. * For complete information about known issues please refer to the MODIS/VIIRS Land Quality Assessment website.

The Terra and Aqua combined MCD64A1 Version 6.1 Burned Area data product is a monthly, global gridded 500 meter (m) product containing per-pixel burned-area and quality information. The MCD64A1 burned-area mapping approach employs 500 m Moderate Resolution Imaging Spectroradiometer (MODIS) Surface Reflectance imagery coupled with 1 kilometer (km) MODIS active fire observations. The algorithm uses a burn sensitive Vegetation Index (VI) to create dynamic thresholds that are applied to the composite data. The VI is derived from MODIS shortwave infrared atmospherically corrected surface reflectance bands 5 and 7 with a measure of temporal texture. The algorithm identifies the date of burn for the 500 m grid cells within each individual MODIS tile. The date is encoded in a single data layer as the ordinal day of the calendar year on which the burn occurred with values assigned to unburned land pixels and additional special values reserved for missing data and water grid cells. The data layers provided in the MCD64A1 product include Burn Date, Burn Data Uncertainty, Quality Assurance, along with First Day and Last Day of reliable change detection of the year. Known Issues * For complete information about known issues please refer to the MODIS/VIIRS Land Quality Assessment website.
