Sentinel-1 Extended Time Annotation Products (ETAD)

This collection offers Sentinel-1 Level-1 Single Look Complex (SLC) products captured in the modes Interferometric Wide Swath (IW), Extra Wide Swath (EW), and Strip Map Mode (SM). Level-1 SLC products are images in the slant range by azimuth imaging plane, in the image plane of satellite data acquisition. Each image pixel is represented by a complex (I and Q) magnitude value and therefore contains both amplitude and phase information. Each I and Q value is 16 bits per pixel. The processing for all SLC products results in a single look in each dimension using the full available signal bandwidth. The imagery is geo-referenced using orbit and attitude data from the satellite. SLC images are produced in a zero Doppler geometry. This convention is common with the standard slant range products available from other SAR sensors.

Level-1 Ground Range Detected (GRD) products consist of focused SAR data that has been detected, multi-looked and projected to ground range using the Earth ellipsoid model WGS84. The ellipsoid projection of the GRD products is corrected using the terrain height specified in the product general annotation. The terrain height used varies in azimuth and it is constant in range (For IW/EW modes only the terrain height of first subswath is considered)

This Collection provides Sentinel-3 SRAL Level-1A products, which contains geo-located bursts of echoes with all calibrations applied.

This Collection provides Sentinel-3 SRAL Level-1A products, which contains geo-located bursts of echoes with all calibrations applied.

The Sentinel-1 mission is a constellation of two polar-orbiting satellites, operating day and night performing C-band synthetic aperture radar imaging. The Sentinel-1 Radiometrically Terrain Corrected (RTC) data in this collection is a radiometrically terrain corrected product derived from the Ground Range Detected (GRD) Level-1 products produced by the European Space Agency. The RTC processing is performed by Catalyst. Radiometric Terrain Correction accounts for terrain variations that affect both the position of a given point on the Earth's surface and the brightness of the radar return, as expressed in radar geometry. Without treatment, the hill-slope modulations of the radiometry threaten to overwhelm weaker thematic land cover-induced backscatter differences. Additionally, comparison of backscatter from multiple satellites, modes, or tracks loses meaning. A Planetary Computer account is required to retrieve SAS tokens to read the RTC data. See the documentation for more information. ### Methodology The Sentinel-1 GRD product is converted to calibrated intensity using the conversion algorithm described in the ESA technical note ESA-EOPG-CSCOP-TN-0002, Radiometric Calibration of S-1 Level-1 Products Generated by the S-1 IPF. The flat earth calibration values for gamma correction (i.e. perpendicular to the radar line of sight) are extracted from the GRD metadata. The calibration coefficients are applied as a two-dimensional correction in range (by sample number) and azimuth (by time). All available polarizations are calibrated and written as separate layers of a single file. The calibrated SAR output is reprojected to nominal map orientation with north at the top and west to the left. The data is then radiometrically terrain corrected using PlanetDEM as the elevation source. The correction algorithm is nominally based upon D. Small, “Flattening Gamma: Radiometric Terrain Correction for SAR Imagery”, IEEE Transactions on Geoscience and Remote Sensing, Vol 49, No 8., August 2011, pp 3081-3093. For each image scan line, the digital elevation model is interpolated to determine the elevation corresponding to the position associated with the known near slant range distance and arc length for each input pixel. The elevations at the four corners of each pixel are estimated using bilinear resampling. The four elevations are divided into two triangular facets and reprojected onto the plane perpendicular to the radar line of sight to provide an estimate of the area illuminated by the radar for each earth flattened pixel. The uncalibrated sum at each earth flattened pixel is normalized by dividing by the flat earth surface area. The adjustment for gamma intensity is given by dividing the normalized result by the cosine of the incident angle. Pixels which are not illuminated by the radar due to the viewing geometry are flagged as shadow. Calibrated data is then orthorectified to the appropriate UTM projection. The orthorectified output maintains the original sample sizes (in range and azimuth) and was not shifted to any specific grid. RTC data is processed only for the Interferometric Wide Swath (IW) mode, which is the main acquisition mode over land and satisfies the majority of service requirements.

This collection offers Sentinel-1 Level-2 Ocean (OCN) products captured in Wave Mode (WV). Level-2 OCN products are specifically processed radar data. These products consist of geo-located geophysical parameters derived from Sentinel-1 Level-1 SAR data and are composed of three components: an Ocean Swell Spectra (OSW) component, an Ocean Wind Field (OWI) component, and a Radial Velocity (RVL) component. The OWI component is a ground-range gridded estimate of the surface wind speed and direction at 10 m above the surface. The OSW component is a two-dimensional ocean surface swell spectrum and includes an estimate of wind speed and direction for each swell spectrum. The OSW component provides continuous measurements of SAR swell spectra at C-band. The RVL surface radial velocity component is a ground-range gridded difference between the measured Level-2 Doppler grid and the geometrical Doppler calculated from Level-1 data. The RVL component provides continuity with the ASAR Doppler grid. OCN products are generated from all four Sentinel-1 imaging modes. In SM mode, the OCN product contains all three components. In IW and EW modes, the OCN product contains only OWI and RVL. In WV mode, the OCN product contains only OSW and RVL.
