Southwest Kansas Burned Area Polygon Derived from Sentinel-2 NBR

Date of Image: May 19, 2026 Date of Next Image: None Expected Summary: The polygon was derived from a combination of a normalized burn ratio (NBR) thresholding derived via Sentinel-2 near-infrared (NIR) and shortwave-infrared bands and a simple single-band NIR threshold from the same image. The NBR threshold for the binary burned classification was set to values Credits: USGS, Landsat, Clayton Elder (ARC) Esri REST Endpoint: See URL to the right. WMS Endpoint: https://gis.earthdata.nasa.gov/portal/services/DISASTERS_202605_FIRE_KS/202608_landsat_nbrburnperimeter/MapServer/WMSServer

Date of Image: May 19, 2026 Date of Next Image: None Expected Summary: The polygon was derived from a combination of a normalized burn ratio (NBR) thresholding derived via Sentinel-2 near-infrared (NIR) and shortwave-infrared bands and a simple single-band NIR threshold from the same image. The NBR threshold for the binary burned classification was set to values Credits: USGS, Landsat, Clayton Elder (ARC) Esri REST Endpoint: See URL to the right. WMS Endpoint:

Dates of Images: Post-Event: May 16, 2026 Pre-Event: May 11, 2026 Date of Next Image: Updated images are expected to be available for additional analysis as needed up to every 6 days. For lower-latency information regarding fire extent and estimated burn area, please see the Fire Events Data Suite (FEDS) web map. Summary: These pre-fire and post-fire images pair were analyzed for normalized burn ratio (NBR). The input images were generated from the Sentinel-2 dataset at 10m resolution. NBR is defined mathematically as (NIR – SWIR)/(NIR + SWIR) where NIR is near-infrared and SWIR is short-wave infrared. dNBR is computed by the difference between the pre-fire NBR and the post-fire NBR. More information on dNBR can be found here: https://un-spider.org/advisory-support/recommended-practices/recommended-practice-burn-severity/in-detail/normalized-burn-ratio. dNBR data may be computed while the fire is in progress. This is intentionally done to prioritize rapid data availability for proactive disaster response but means data can change over the course of the fire. Check fire containment and image dates for further context on image timing. Suggested Use: dNBR is commonly used as a proxy to identify fire-affected areas. Higher dNBR value are statistically correlated with greater burn severity, where negative dNBR values may represent a re-greening of or growth of vegetation in between pre and post-vegetation. The use of this dNBR product as a quantitative metric of burn severity at the time of posting this dataset should be strongly caveated. This is due to several dNBR limitations: The spectral band selections used for dNBR calculations, and the implication of changes observed following fire in those wavelengths, primarily pertain to how vegetation spectral signatures change in NIR and SWIR wavelengths following charring. Because of this, dNBR will not accurately describe burned surfaces that are not vegetation (e.g. human built infrastructure), and the interpretation of dNBR values may vary widely based on the type of vegetation burned. This dataset has not been validated by independent burn severity assessments. The degree to which dNBR is accurately determined depends on careful selection of pre and post event imagery. An effort was made to use the highest quality imagery (i.e. cloud free) with representative conditions for each scene; however, it is unknown at the time of this posting how selection of different pre/post image pairs could affect the derived dNBR values. Satellite/Sensor: Copernicus Sentinel-2 Resolution: 10 meters Credits: NASA/MSFC, ESA Copernicus Service URL: See URL to the bottom right. WMS Endpoint: https://gis.earthdata.nasa.gov/portal/services/DISASTERS_202605_FIRE_KS/202608_sentinel2_dnbr/ImageServer/WMSServer

Dates of Images: Post-Event: May 16, 2026 Pre-Event: May 11, 2026 Date of Next Image: Unknown Summary: These pre-fire and post-fire images pair were analyzed for normalized burn ratio (NBR). The input images were generated from the Harmonized Landsat Sentinel-2 (HLS) dataset at 30m resolution. NBR is defined mathematically as (NIR – SWIR)/(NIR + SWIR) where NIR is near-infrared and SWIR is short-wave infrared. Check fire containment and image dates for further context on image timing. Suggested Use: NBR is commonly used as a proxy to indicate areas which have charred vegetation. Darker areas (more negative values) in the NBR image more strongly represent the presence of burned vegetation. This dataset has not been validated by independent burn severity assessments. Satellite/Sensor: Harmonized Landsat Sentinel-2 data: https://www.earthdata.nasa.gov/data/projects/hls Resolution: 30 meters Credits: NASA/MSFC, USGS, ESA Copernicus Service URL: See individual Layers.

Dates of Images: Post-Event: May 19, 2026 Pre-Event: May 11, 2026 Date of Next Image: Unknown Summary: These pre-fire and post-fire images pair were analyzed for normalized burn ratio (NBR). The input images were generated from the Sentinel-2 dataset at 10m resolution. NBR is defined mathematically as (NIR – SWIR)/(NIR + SWIR) where NIR is near-infrared and SWIR is short-wave infrared. dNBR is computed by the difference between the pre-fire NBR and the post-fire NBR. More information on dNBR can be found here: https://un-spider.org/advisory-support/recommended-practices/recommended-practice-burn-severity/in-detail/normalized-burn-ratio. dNBR data may be computed while the fire is in progress. This is intentionally done to prioritize rapid data availability for proactive disaster response but means data can change over the course of the fire. Check fire containment and image dates for further context on image timing. Suggested Use: NBR is commonly used as a proxy to indicate areas which have charred vegetation. Darker areas (more negative values) in the NBR image more strongly represent the presence of burned vegetation. Since the dNBR considers the condition of the scene before the fire occurred, the resulting value has been used as a proxy for burn severity. Higher dNBR values represent a proxy for greater burn severity. Negative dNBR values may represent a re-greening of or growth of vegetation in between pre and post imagery. The use of this dNBR product as a quantitative metric of burn severity at the time of posting this dataset should be strongly caveated. This is due to several dNBR limitations: The spectral band selections used for dNBR calculations, and the implication of changes observed following fire in those wavelengths, primarily pertain to how vegetation spectral signatures change in NIR and SWIR wavelengths following charring. Because of this, dNBR may not accurately describe burned surfaces that are not vegetation (e.g. human built infrastructure). This dataset has not been validated by independent burn severity assessments. The degree to which dNBR is accurately determined depends on careful selection of pre and post event imagery. An effort was made to use the highest quality imagery (i.e. cloud free) with representative conditions for each scene; however, it is unknown at the time of this posting how selection of different pre/post image pairs could affect the derived dNBR values. Satellite/Sensor: Copernicus Sentinel-2 Resolution: 10 meters Credits: NASA/MSFC, ESA Copernicus Service URL: See URL to the bottom right. WMS Endpoint: https://gis.earthdata.nasa.gov/portal/services/DISASTERS_202605_FIRE_KS/202608_landsat_dnbr/ImageServer/WMSServer

Dates of Images: Post-Event: May 16, 2026 Pre-Event: May 11, 2026 Date of Next Image: None Summary: The True Color RGB composite provides a product of how the surface would look to the naked eye from space. The RGB is created using the red, green, and blue channels of the respective instrument. Suggested Use: The True Color RGB provides a product of how the surface would look to the naked eye from space. The True Color RGB is produced using the 3 visible wavelength bands (red, green, and blue) from the respective sensor. Some minor atmospheric corrections have occurred. Satellite/Sensor: MultiSpectral Instrument (MSI) on European Space Agency's (ESA) Copernicus Sentinel-2A/2B satellites Resolution: 10 meters Credits: NASA/MSFC, USGS, ESA Copernicus Esri REST Endpoint: See URL section on right side of page WMS Endpoint: https://gis.earthdata.nasa.gov/portal/services/DISASTERS_202605_FIRE_KS/202608_sentinel2/ImageServer/WMSServer
