Athletes in Action Campus - 10/10/2025

NOTE: Due to the higher resolution of this data, it may be slow to load or require the user to zoom to a smaller area of interest. Date of Images: Post-Event: 7/11/2026, 7/12/2026 Pre-Event: Date of Next Image: Unknown Summary: Skysat is a high-resolution satellite constellation operated by Planet and allows for multiple viewing opportunities of any location on Earth daily. Skysat collects 4-band imagery which allows for multiple derived products to be produced. The True Color RGB composite provides a product of how the surface would look to the naked eye from space. The RGB is created using the red, green, and blue channels of the respective instrument. The Color Infrared composite is created using the near-infrared, red, and green channels. The near-infrared gives the ability to see through thin clouds. Healthy vegetation is shown as red, water is in blue. Normalized Differential Vegetation Index (NDVI) maps are produced by converting pixel values to NDVI = (Red – NIR)/(Red + NIR), NIR indicates the near infrared band. The dynamically generated Normalized Difference Vegetation Index (NDVI) layer is an index for quantifying green vegetation. It reflects the state of vegetation health based on how vegetation reflects light at certain wavelengths. Suggested Use: The True Color RGB provides a product of how the surface would look to the naked eye from space and may show damage caused by severe weather. The True Color RGB is produced using the 3 visible wavelength bands (red, green, and blue) from the respective sensor. Some minor atmospheric corrections have occurred. A Color Infrared composite depicts healthy vegetation as red, water as blue. Some minor atmospheric corrections have occurred. For NDVI, dark green colors are areas with a lot of green leaf growth which indicates the presence of chlorophyll. Chlorophyll reflects more infrared light and less visible light. Areas with some green leaf growth are in light greens, and areas with little to no vegetation growth are even lighter greens. Resolution: ~1 meter Esri REST Endpoint: See URL section on right side of page of individual layers below.

Date of Image(s) Sentinel-1 Synthetic Aperture Radar (SAR): 12/28/2024 (Pre-fire) 01/09/2025 (Called post-fire, but fires may still burning) Sentinel-2 MultiSpectral Instrument (MSI): 01/02/2025 (Pre-fire) 01/12/2025 (Called post-fire, but fires may still burning) Ancillary data ESA Global Land Cover in 2021 01/23/2025 Summary The burned areas and burn severity levels for vegetation and urban areas were generated separately based on an integration of Sentinel-2 and Sentinel-1 data. Specifically, the Sentinel-2 MSI data provide large changes in vegetation reflectance after burning due to changes in near-infrared (NIR) and shortwave-infrared (SWIR) bands, but changes in these spectral ranges were less obvious or nonexistent in affected urban environments. In a complementary sense, Sentinel-1 synthetic aperture radar (SAR) is sensitive to surface roughness changes, a signal which is more apparent (usually rougher or higher backscatter) due to the fire destruction of built infrastructure. Thus, we leveraged these two key physical characteristics together to distinguish the urban-burned areas and vegetation-burned areas. Note that while the magnitude of calculated changes in NIR, SWIR, and SAR backscatter in pre-and post-event imagery imply a range of burn severity, these metrics are still considered proxies for actual burn severity and should be interpreted as such. We first calculated the differenced Normalized Burn Ratio (dNBR = NBR_pre – NBR_post) from Sentinel-2 data in which the NBR = (NIR – SWIR)/(NIR+SWIR). This provides critical changes in vegetation due to burning. Second, we calculated the differenced vertical/horizontal polarization (VH) backscatter (dVH = VH_post – VH_pre) from Sentinel-1 SAR data. The ESA Land Cover classification map and the relationship between dNBR and dVH were used to distinguish urban and vegetation-burned areas. The generated dNBR was used to divide the vegetation-burned areas into 4 groups: Low (values ≤0.25), Moderate (0.250.45). The generated dVH was used to divide the urban-burned areas into 3 groups: Low (values ≤1), Moderate (14). Notes that these thresholds were defined for contrast visualization of severity levels across four southern California fires and may not reflect other regions. All analysis was performed in Google Earth Engine. From these layers, we can clearly see the vegetation and urban-burned areas and their burn levels. The structure damage could be overlayed on top of burn maps generated by the integration of Sentinel-1 and -2. The maps were preliminary results only and no ground-validation has been considered at the time of posting. To separate vegetation and urban-burned areas, we applied the empirical thresholds of Sentinel-2 dNBR and Sentinel-1 dVH, which could be imperfect in some locations on a large scale. Sentinel-1 SAR data was subject to signal noise in some areas likely due to terrain and speckle noise, which could lead to incorrect severity levels in urban-burned areas to some extents. Refinement of the results is in progress. Suggested Usage Despite the rawer form of this quick-look product, it is still useful for distinguishing vegetation and urban-burned areas and severity assessment. Resolution Sentinel-1A SAR C-band, 10m spatial resolution Sentinel-2 MSI, 10-60m spatial resolution Credits Khuong Tran (ARC), Taejin Park (ARC), Aakash Chhabra (ARC), Weile Wang (ARC), Kyle Kabasares (ARC). Service URL https://gis.earthdata.nasa.gov/portal/home/item.html?id=88fe789c74f9459392d293931ac7aac5 WMS Endpoint https://gis.earthdata.nasa.gov/portal/services/DISASTERS_202501_FIRE_CA/2501_s1_s2_burnseverity/ImageServer/WMSServer

Date of Images: Pre-Landfall: HLS: 9/27/2024 - 10/7/2024 Sentinel-1: 10/3/2024, 10/8/2024 Post-Landfall: Sentinel-1: 10/10/2024, 10/11/2024 Summary: The Advanced Rapid Imaging and Analysis (ARIA) and Observational Products for End-Users from Remote Sensing Analysis (OPERA) teams at NASA's Jet Propulsion Laboratory and California Institute of Technology derived the surface water extent maps from the OPERA Dynamic Surface Water Extent (DSWx) from NASA Harmonized Landsat Sentinel-2 (HLS) and Sentinel-1 (DSWx-S1) products. The results posted here are preliminary and unvalidated results, primarily intended to aid the field response and people who wanted to have a rough first look at the inundation extent. The ARIA-share website has always focused on posting preliminary results as fast as possible for disaster response. OPERA DSWx-S1 The OPERA DSWx-S1 data identifies surface water and inundated vegetation. We provide the Water (WTR) layers. Images are provided from 1) October 3, 2024, 2) October 8, 2024, 3) October 10, 2024, and 4) October 11, 2024. Each image consists of multiple MGRS tiles that were merged together for a composite image saved as a GeoTIFF file. ARIA/OPERA water change map derived from OPERA DSWx-S1 The ARIA/OPERA water change map is derived from two OPERA DSWx-S1 Binary Water (BWTR) images. Change maps are made for images taken on October 3, 2024 and October 11, 2024 and for October 8, 2024, and October 11, 2024. The BWTR combines inundated vegetation and open water into a single water class. These maps depict areas of new water detection (or loss). The change map includes values of: (0) indicate no change between images, (1) absence of water pre-event, presence of water during-event, and (-1) presence of water pre-event, absence of water during-event. OPERA DSWx-HLS The OPERA DSWx-HLS was used to identify surface water using the WTR layer. 378 images were examined from 2024-09-27 to 2024-10-07, prioritizing pixels classified as open surface water. Pixels flagged as snow/ice in the HLS Fmask were reclassified to water. The mosaic image consists of multiple MGRS tiles that were merged together for a composite image saved as a GeoTIFF file. Suggested Use: OPERA DSWx-S1 The OPERA DSWx-S1 products classifies the OPERA Radiometric Terrain Corrected SAR backscatter from Sentinel-1 (RTC-S1) input imagery into: not water, water, and inundated vegetation with the masks such as layover/shadow mask and HAND mask. The WTR layer includes all classes. Open water and inundated vegetation are represented in blue and green in WTR. Areas with masks are gray. The masks include the layover/shadow mask and HAND mask. Areas with no water detected are transparent. Transparent: Not Water Blue: Water Green: Inundated Vegetation Gray: Layover/Shadow/Hand Masks ARIA/OPERA water change map derived from OPERA DSWx-S1 The ARIA/OPERA water extent change map classifies water extent into change/no change. Transparent (0): No Change Red (1): increased water extent Gray (-1): decreased water extent OPERA DSWx-HLS-WTR The OPERA DSWx-HLS Water product classifies the Harmonized Landsat Sentinel-2 (HLS) input imagery into "not water", "open surface water", and "partial surface water". The "HLS cloud/cloud shadow" and "HLS snow/ice" layers are direct inputs from the HLS FMask. Transparent (0): No Water Blue (1): Open Water Light Blue (2): Partial Surface Water Gray (253): HLS Cloud/Cloud Shadow This layer is meant to provide users with a quick view for water/no-water. Invalid data classes (snow/ice and cloud/cloud shadow along with adjacent to cloud/cloud shadow) are also provided to indicate areas in which the water classification does not provide water/no-water classification. Note: Sediment rich water is sometimes misclassified as snow/ice by the HLS Fmask. As such, we have reclassified any of the snow/ice pixels to water for these images. For more information about how the OPERA DSWx-HLS Water product classifies data: https://d2pn8kiwq2w21t.cloudfront.net/documents/ProductSpec_DSWX_URS309746.pdf Satellite/Sensor: Synthetic Aperture Radar (SAR) instrument on European Space Agency's (ESA) Sentinel-1A satellite Harmonized Landsat Sentinel-2 (HLS): MultiSpectral Instrument (MSI) on European Space Agency's (ESA) Copernicus Sentinel-2A/2B satellites and Operational Land Imager (OLI) on the NASA/USGS Landsat 8 satellite Resolution: 30 meters The DSWx-S1 products have these flags: 250 (light gray) and 251 (dark gray) represent HAND and layover/shadow masks, respectively. HAND mask (light gray, value 250) delineates regions where the terrain's elevation exceeds a specified threshold relative to the height above the nearest drainage point, indicating areas less likely to be subject to direct inundation. Layover/shadow mask (dark gray, value 251) identifies zones that are either occluded by topographic features taller than the surrounding landscape (layover) or are not illuminated by the radar signal due to obstruction by these elevated features (shadow), leading to potential data voids in SAR imagery. Credits: NASA JPL-Caltech ARIA/OPERA Team Sentinel-1 data were accessed through the Copernicus Open Hub and the Alaska Satellite Facility server. The product contains modified Copernicus Sentinel data (2024), processed by the European Space Agency and analyzed by the NASA-JPL/Caltech ARIA and OPERA team. The products are produced as part of the OPERA project, which is funded by NASA to address remote sensing needs identified by the Satellite Needs Working Group, and managed by NASA's Jet Propulsion Laboratory. HLS data was accessed through NASA EarthData Search. The product contains modified Copernicus Sentinel data (2024), processed by the European Space Agency, NASA/USGS Landsat 8 data, and analyzed by the NASA-JPL/Caltech ARIA and OPERA team. The products are produced as part of the OPERA project, which is funded by NASA to address remote sensing needs identified by the Satellite Needs Working Group, and managed by NASA's Jet Propulsion Laboratory. The OPERA DSWx products have been in production since September 2024, are freely distributed to the public via NASA's Physical Oceanography Distributed Active Archive Center (PO.DAAC), and can be downloaded through NASA's Earthdata search. For more information about the Dynamic Surface Water eXtent product suite, please refer to the DSWx Product page: https://www.jpl.nasa.gov/go/opera/products/dswx-product-suite. For more information about the Caltech-JPL ARIA project, visit https://aria.jpl.nasa.gov. For more information about the JPL OPERA project, visit https://www.jpl.nasa.gov/go/opera. Data Download: https://aria-share.jpl.nasa.gov/20241010-Hurricane_Milton/DSWx/ Service URL: https://gis.earthdata.nasa.gov/portal/home/item.html?id=84fe3b39b6ac482e8e8de954eb4677fe WMS: https://gis.earthdata.nasa.gov/portal/services/DISASTERS_202410_HURRICANE_MILTON/2428_opera_dswx_hls/ImageServer/WMSServer

Dates of Images: Post-Event: October 21, October 18 Date of Next Image: Unknown Summary: The True Color RGB composite provides a product of how the surface would look to the naked eye from space. The RGB is created using the red, green, and blue channels of the respective instrument. The Short Wave Infrared (SWIR) RGB is a product that is created using the SWIR, NIR, and Red channels of the respective instrument. The Color Infrared composite is created using the near-infrared, red, and green channels. The near-infrared gives the ability to see through thin clouds. Healthy vegetation is shown as red, water is in blue. Suggested Use: The True Color RGB provides a product of how the surface would look to the naked eye from space. The True Color RGB is produced using the 3 visible wavelength bands (red, green, and blue) from the respective sensor. Some minor atmospheric corrections have occurred. The Short Wave Infrared (SWIR) RGB is a product that can provides value in flood detection. Areas of water will appear blue, healthy green vegetation will appear as a bright green, urban areas in various shades of magenta, snow will appear as a bright blue/cyan, and bare soils being multicolor dependent on their makeup. Compare pre-event imagery to post-event imagery to identify potential flooding. A Color Infrared composite depicts healthy vegetation as red, water as blue. Some minor atmospheric corrections have occurred. Satellite/Sensor: MultiSpectral Instrument (MSI) on European Space Agency's (ESA) Copernicus Sentinel-2A/2B satellites Resolution: True Color: 10 meters Credits: NASA/MSFC, USGS, ESA Copernicus Esri REST Endpoint: See URL section on right side of page WMS Endpoint: https://gis.earthdata.nasa.gov/portal/services/DISASTERS_202510_FLOOD_AK/202510_sentinel2/ImageServer/WMSServer

uav imagery by North Metro Fire Rescue District, acquired 2026-08-20 to 2026-08-20, 3.2 cm per pixel, published on OpenAerialMap.

Military Installations; National Park Service Areas; Correctional Facilities; Colleges and Universities
