Global elevation data

The Sentinel-1 mission is a constellation of two polar-orbiting satellites, operating day and night performing C-band synthetic aperture radar imaging. The Sentinel-1 Radiometrically Terrain Corrected (RTC) data in this collection is a radiometrically terrain corrected product derived from the Ground Range Detected (GRD) Level-1 products produced by the European Space Agency. The RTC processing is performed by Catalyst. Radiometric Terrain Correction accounts for terrain variations that affect both the position of a given point on the Earth's surface and the brightness of the radar return, as expressed in radar geometry. Without treatment, the hill-slope modulations of the radiometry threaten to overwhelm weaker thematic land cover-induced backscatter differences. Additionally, comparison of backscatter from multiple satellites, modes, or tracks loses meaning. A Planetary Computer account is required to retrieve SAS tokens to read the RTC data. See the documentation for more information. ### Methodology The Sentinel-1 GRD product is converted to calibrated intensity using the conversion algorithm described in the ESA technical note ESA-EOPG-CSCOP-TN-0002, Radiometric Calibration of S-1 Level-1 Products Generated by the S-1 IPF. The flat earth calibration values for gamma correction (i.e. perpendicular to the radar line of sight) are extracted from the GRD metadata. The calibration coefficients are applied as a two-dimensional correction in range (by sample number) and azimuth (by time). All available polarizations are calibrated and written as separate layers of a single file. The calibrated SAR output is reprojected to nominal map orientation with north at the top and west to the left. The data is then radiometrically terrain corrected using PlanetDEM as the elevation source. The correction algorithm is nominally based upon D. Small, “Flattening Gamma: Radiometric Terrain Correction for SAR Imagery”, IEEE Transactions on Geoscience and Remote Sensing, Vol 49, No 8., August 2011, pp 3081-3093. For each image scan line, the digital elevation model is interpolated to determine the elevation corresponding to the position associated with the known near slant range distance and arc length for each input pixel. The elevations at the four corners of each pixel are estimated using bilinear resampling. The four elevations are divided into two triangular facets and reprojected onto the plane perpendicular to the radar line of sight to provide an estimate of the area illuminated by the radar for each earth flattened pixel. The uncalibrated sum at each earth flattened pixel is normalized by dividing by the flat earth surface area. The adjustment for gamma intensity is given by dividing the normalized result by the cosine of the incident angle. Pixels which are not illuminated by the radar due to the viewing geometry are flagged as shadow. Calibrated data is then orthorectified to the appropriate UTM projection. The orthorectified output maintains the original sample sizes (in range and azimuth) and was not shifted to any specific grid. RTC data is processed only for the Interferometric Wide Swath (IW) mode, which is the main acquisition mode over land and satisfies the majority of service requirements.

The GEBCO grid is a global terrain model for ocean and land, providing elevation in metres on a 15 arc-second interval grid. It is maintained by the General Bathymetric Chart of the Oceans under the International Hydrographic Organization and UNESCO's Intergovernmental Oceanographic Commission.

This Collection provides Copernicus DEM COG products, which represent the surface of the Earth including buildings, infrastructure and vegetation, in resolution of 90 meters.

This Collection provides Copernicus DEM COG products, which represent the surface of the Earth including buildings, infrastructure and vegetation, in resolution of 30 meters.

U.S.-wide digital elevation data at horizontal resolutions ranging from one to sixty meters. The USGS 3D Elevation Program (3DEP) Datasets from the National Map are the primary elevation data product produced and distributed by the USGS. The 3DEP program provides raster elevation data for the conterminous United States, Alaska, Hawaii, and the island territories, at a variety of spatial resolutions. The seamless DEM layers produced by the 3DEP program are updated frequently to integrate newly available, improved elevation source data. DEM layers are available nationally at grid spacings of 1 arc-second (approximately 30 meters) for the conterminous United States, and at approximately 1, 3, and 9 meters for parts of the United States. Most seamless DEM data for Alaska is available at a resolution of approximately 60 meters, where only lower resolution source data exist.

Land area in km² per 5 arcminute cell. This layer is part of the Global Roads Inventory Project (GRIP) dataset, developed to provide a more recent and consistent global roads dataset for use in global environmental and biodiversity assessment models like GLOBIO. **Data publication:** 2018-01-01 **Supplemental Information:** The original GRIP dataset consists of global and regional vector datasets in ESRI geodatabase and shapefile format. It is also available as global raster datasets of road density at a 5 arcminutes resolution (~8x8km) from which the land area component has been extracted.. GRIP version 4 (GRIP4) is based on many different sources, including OpenStreetMap. The UNSDI-Transportation datamodel was applied for harmonization of the individual source datasets. GRIP4 is provided under a Creative Commons License (CC-0) and is free to use. **Citation:** Citations and acknowledgements of the GRIP dataset should be made as follows: Meijer, J.R., Huijbegts, M.A.J., Schotten, C.G.J. and Schipper, A.M. (2018): Global patterns of current and future road infrastructure. Environmental Research Letters, 13-064006 **Contact points:** Metadata Contact: [GLOBIO](mailto:info.globio@pbl.nl) **Data lineage:** Data quality information not available **Resource constraints:** This work is made available under the license Creative Commons Zero (CC0) **Online resources:** Globio info Global patterns of current and future road infrastructure. Meijer et al (2018) Env. Res. Letters

The Terra Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) Global Water Bodies Database (ASTWBD) Version 1 data product provides global coverage of water bodies larger than 0.2 square kilometers at a spatial resolution of 1 arc second (approximately 30 meters) at the equator, along with associated elevation information. The ASTWBD data product was created in conjunction with the ASTER Global Digital Elevation Model (ASTER GDEM) Version 3 data product by the Sensor Information Laboratory Corporation (SILC) in Tokyo. The ASTER GDEM Version 3 data product was generated using ASTER Level 1A scenes acquired between March 1, 2000, and November 30, 2013. The ASTWBD data product was then generated to correct elevation values of water body surfaces. To generate the ASTWBD data product, water bodies were separated from land areas and then classified into three categories: ocean, river, or lake. Oceans and lakes have a flattened, constant elevation value. The effects of sea ice were manually removed from areas classified as oceans to better delineate ocean shorelines in high latitude areas. For lake water bodies, the elevation for each lake was calculated from the perimeter elevation data using the mosaic image that covers the entire area of the lake. Rivers presented a unique challenge given that their elevations gradually step down from upstream to downstream; therefore, visual inspection and other manual detection methods were required. The geographic coverage of the ASTWBD extends from 83°N to 83°S. Each tile is distributed in GeoTIFF format and referenced to the 1984 World Geodetic System (WGS84)/1996 Earth Gravitational Model (EGM96) geoid. Each data product is provided as a zipped file that contains an attribute file with the water body classification information and a DEM file, which provides elevation information in meters.

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) Shuttle Radar Topography Mission (SRTM), which includes the global 1 arc second (~30 meter) number product. The NASA SRTM data sets result from a collaborative effort by the National Aeronautics and Space Administration (NASA) and the National Geospatial-Intelligence Agency (NGA - previously known as the National Imagery and Mapping Agency, or NIMA), as well as the participation of the German and Italian space agencies. This collaboration aims to generate a near-global digital elevation model (DEM) of Earth using radar interferometry. SRTM was the primary (and virtually only) payload on the STS-99 mission of the Space Shuttle Endeavour, which launched February 11, 2000 and flew for 11 days. The SRTM swaths extended from ~30 degrees off-nadir to ~58 degrees off-nadir from an altitude of 233 kilometers (km), creating swaths ~225 km wide, and consisted of all land between 60° N and 56° S latitude to account for 80% of Earth's total landmass. Ancillary one-byte (0 to 255) "NUM" (number) files were produced for NASA SRTM Version 3. These files have names corresponding to the elevation files, except with the extension ".NUM" (such as N37W105.NUM). The elevation files use the extension ".HGT", meaning height (such as N37W105.HGT). The separate NUM file indicates the source of each DEM pixel; the number of ASTER scenes used (up to 100), if ASTER; and the number of SRTM data takes (up to 24), if SRTM. The global 1 arc second number product is also available in NetCDF4 format as the SRTMGL1_NUMNC dataset and can be used with the corresponding SRTMGL1_NC elevation product. Known Issues * Known issues in the NASA SRTM are described in the following publication: * Rodriguez, E., C. S. Morris, and J. E. Belz (2006), A global assessment of the SRTM performance, Photogramm. Eng. Remote Sens., 72, 249–260. https://doi.org/10.14358/PERS.72.3.249

Urban 50cm contour map image layer published by connor.spence_UHCC, with keywords naming Upper Hutt City Council and Wellington.

Servizio di base cartografico che utilizza lo shade del DEM con Ortofoto 2014

This layer portrays elevation as an artistic hillshade. The map is designed to be used as a backdrop for topographical, soil, hydro, landcover or other outdoor recreational maps. It’s a default relief background in various basemaps such as Topographic, Terrain with Labels. The map is compiled from a variety of data sources from commercial, community maps and many authoritative organizations across the globe. The basemap has global coverage down to a scale of ~1:72k. In the United States, parts of Europe, Asia and Africa coverage goes down to ~1:9k.  To see the coverage and sources of various datasets comprising this map layer, view the World Elevation Coverage Map. Additionally, this layer uses data from Vantor’s Precision 3D Digital Terrain Models for parts of the globe. The map is based on the Multi-directional hillshade algorithm.

Suitable areas for the construction of fish ponds based on a slope evaluation. Slope was derived from a global digital elevation model (GTOPOP30) in the form of percentages. **Data publication:** 1998-01-01 **Supplemental Information:** This map derives from a wider study that evaluates inland fish farming potential at a continental-level, published by J.Aguilar-Manjarrez and S. S. Nath with the title "A strategic reassessment of fish farming potential in Africa" . CIFA Technical Paper. No. 32. Rome, FAO. 1998. 170p. This study is a follow-up of an earlier assessment of warm-water fish farming potential in Africa by Kapetsky (1994) with the objective to assess locations and areal expanses that have potential for warm-water and temperate-water fish farming in continental Africa. Resolution 5 km x 5 km. **Contact points:** Metadata Contact: [Jose Aguilar-Manjarrez](mailto:Jose.AguilarManjarrez@fao.org) **Data lineage:** Conversion from ASCII files to Arc/Info GRID **Online resources:** Slope suitability for ponds (GRID format) CIFA Tecnical Paper 32 CIFA Tecnical Paper 32 - 8. APPENDIX iiasa.ac.at

The delivery of all Suomi National Polar-orbiting Partnership (Suomi NPP) VIIRS science data products will cease on November 2, 2026 (2026/306). Data users are encouraged to transition to the equivalent VJ228C2 (primary) or VJ128C2 (secondary) data products. The NASA/NOAA Suomi National Polar-orbiting Partnership (Suomi NPP) Visible Infrared Imaging Radiometer Suite (VIIRS) Water Reservoir 8-day Level 3 (L3) Global (VNP28C2) Version 2 product provides current data for 151 man-made reservoirs and 13 regulated natural lakes for a total of 164 reservoirs. The VNP28C2 data product provides an 8-day time series of surface area, elevation, and water storage. Datasets are combined with pre-established Area-Elevation (A-E) curves and image classifications of near-infrared (NIR) reflectance from the surface reflectance product acquired by the VIIRS satellite (VNP09H1). The VNP28C2 data product consists of a single variable with information about the reservoir identifier, dam location (longitude and latitude), reservoir surface area, elevation, and water storage capacity. Known Issues * Water occurrence images generally show smaller surface area dynamics in high latitude regions, creating pixels with low occurrence values that have relatively large uncertainties. In addition, the quality of raw water area classification can be affected by lake ice coverage typically creating an overestimation of surface area in the enhancement algorithm. This issue will be addressed in a future release of the enhancement algorithm. For additional information about known issues, refer to the User Guide.

The Visible Infrared Imaging Radiometer Suite (VIIRS) Moderate Resolution Terrain Correction Geolocation (VJ103MODLL) Version 2.1 product from the NOAA-20 VIIRS sensor is produced in 6 minute temporal satellite increments (swaths) at 750 meter resolution. Intersecting the VIIRS line of sight vector with Earth’s geoid and the World Geodetic System (WGS) ellipsoid, this product is based on the SRTM30 Version 2 digital elevation model (DEM), which uses GTOPO30 data for areas from 60° North to 60° South. VJ103MODLL is a terrain correction geolocation product that provides the spatial location for various VIIRS data products. Each swath of data is approximately 3,060 kilometers along track (long) and 3,060 kilometers across track (wide). Provided in the VJ103MODLL product are variables for height, latitude, and longitude. These Science Data Sets (SDS) variables are used in conjunction with the (VJ114) swath product for accurate geolocation information. Known Issues * For complete information about known issues please refer to the MODIS/VIIRS Land Quality Assessment website.

The Terra Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) Level 1 Precision Terrain Corrected Registered At-Sensor Radiance (AST_L1T) data contains calibrated at-sensor radiance, which corresponds with the ASTER Level 1B (AST_L1B) that has been geometrically corrected and rotated to a north-up UTM projection. The AST_L1T is created from a single resampling of the corresponding ASTER L1A (AST_L1A) product. The bands available in the AST_L1T depend on the bands in the AST_L1A and can include up to three Visible and Near Infrared (VNIR) bands, six Shortwave Infrared (SWIR) bands, and five Thermal Infrared (TIR) bands. The AST_L1T dataset does not include the aft-looking VNIR band 3. The AST_L1T product has a spatial resolution of 15 meters (m) for the VNIR bands, 30 m for the SWIR bands, and 90 m for the TIR bands. The precision terrain correction process incorporates GLS2000 digital elevation data with derived ground control points (GCPs) to achieve topographic accuracy for all daytime scenes where correlation statistics reach a minimum threshold. Alternate levels of correction are possible (systematic terrain, systematic, or precision) for scenes acquired at night or that otherwise represent a reduced quality ground image (e.g., cloud cover). For daytime images, if the VNIR or SWIR telescope collected data and precision correction was attempted, each precision terrain corrected image will have an accompanying independent quality assessment. It will include the geometric correction available for distribution as both a text file and single band browse images with the valid GCPs overlaid. This multi-file product also includes georeferenced full resolution browse images. The number of browse images and the band combinations of the images depends on the bands available in the corresponding AST_L1A dataset. Known Issues * TIR bands: Acquisitions for TIR bands ended on January 16, 2026, at 05:10:45 UTC, when the ASTER TIR instrument was permanently turned off due to power limitations on the Terra spacecraft. More information is available in this NASA Science News Brief. * Data acquisition gaps: On November 28, 2024, one of Terra's power-transmitting shunt units failed. As a result, there was insufficient power to maintain functionality of the ASTER instrument. ASTER resumed acquisitions for the VNIR bands on January 18, 2025, and for the TIR bands on April 15, 2025. Users should note the data gap in ASTER acquisitions from November 28, 2024, through January 16, 2025, for VNIR observations, and a gap from November 28, 2024, through April 15, 2025, for TIR acquisitions. * Zero values: Since October 1, 2017, a correction addresses zero-filled scans in low-latitude, ascending orbit (nighttime) TIR data. Additional details are available in the ASTER L1T User Advisory. * SWIR bands: ASTER SWIR detectors are no longer functioning as of January 12, 2009, due to anomalously high SWIR detector temperatures. * SWIR anomaly: Users are advised that ASTER SWIR data acquired from April 2008 to January 11, 2009, exhibit anomalous saturation of values and anomalous striping. This effect is also present for some prior acquisition periods. Please refer to the ASTER SWIR User Advisory for more details.

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of the NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) Digital Elevation Model (DEM) version 1 (NASADEM_HGT) dataset, which provides global elevation data at 1 arc second spacing. NASADEM data products were derived from original telemetry data from the Shuttle Radar Topography Mission (SRTM), a collaboration between NASA and the National Geospatial-Intelligence Agency (NGA), as well as participation from the German and Italian space agencies. SRTM's primary focus was to generate a near-global DEM of the Earth using radar interferometry. It was a primary component of the payload on space shuttle _Endeavour_ during its STS-99 mission, which was launched on February 11, 2000, and flew for 11 days. In addition to Terra Advanced Spaceborne Thermal and Reflection Radiometer (ASTER) Global Digital Elevation Model (GDEM) Version 2 data, NASADEM also relied on Ice, Cloud, and Land Elevation Satellite (ICESat) Geoscience Laser Altimeter System (GLAS) ground control points of its lidar shots to improve surface elevation measurements that led to improved geolocation accuracy. Other reprocessing improvements include the conversion to geoid reference and the use of GDEMs and Advanced Land Observing Satellite Panchromatic Remote-sensing instrument for Stereo Mapping (PRISM) AW3D30 DEM, and interpolation for void filling. NASADEM are distributed in 1 degree latitude by 1 degree longitude tiles and consist of all land between 60° N and 56° S latitude. This accounts for about 80% of Earth's total landmass. NASADEM_HGT data product layers include DEM, number of scenes (NUM), and an updated SRTM water body dataset (water mask). The NUM layer indicates the number of scenes that were processed for each pixel and the source of the data. A low-resolution browse image showing elevation is also available for each NASADEM_HGT granule. The global 1 arc second NASADEM product is also available in NetCDF4 format as the NASADEM_NC dataset with the source of each elevation pixel in the corresponding NASADEM_NUMNC product.

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) SRTM, which includes the global 30 arc second (~1,000 meter) product. The NASA SRTM product with sample spacing of 3 arc second (~90 meter) generated by a 3 X 3 averaging of the 1 arc second data are then 10 X 10 averaged to produce thirty 30 arc second (~1,000 meter) data to correspond with Global 30 Arc Second Elevation (GTOPO30). (See the User Guide Section 2.1.4) The NASA SRTM data sets result from a collaborative effort by the National Aeronautics and Space Administration (NASA) and the National Geospatial-Intelligence Agency (NGA - previously known as the National Imagery and Mapping Agency, or NIMA), as well as the participation of the German and Italian space agencies. This collaboration aims to generate a near-global digital elevation model (DEM) of Earth using radar interferometry. SRTM was the primary (and virtually only) payload on the STS-99 mission of the Space Shuttle Endeavour, which launched February 11, 2000 and flew for 11 days. The SRTM swaths extended from ~30 degrees off-nadir to ~58 degrees off-nadir from an altitude of 233 kilometers (km), creating swaths ~225 km wide, and consisted of all land between 60° N and 56° S latitude to account for 80% of Earth's total landmass. Known Issues * SRTMGL30 is Version 2.1 and has not been updated for the NASA SRTM V3.0 release as described in the User Guide. * Known issues in the NASA SRTM are described in the following publication: * Rodriguez, E., C. S. Morris, and J. E. Belz (2006), A global assessment of the SRTM performance, Photogramm. Eng. Remote Sens., 72, 249–260. https://doi.org/10.14358/PERS.72.3.249

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) Digital Elevation Model (DEM) version 1 (NASADEM_SHHP) dataset, which provides Shuttle Radar Topography Mission (SRTM) global elevation height data at 1 arc second spacing. NASADEM data products were derived from original telemetry data from SRTM, a collaboration between NASA and the National Geospatial-Intelligence Agency (NGA), as well as participation from the German and Italian space agencies. SRTM's primary focus was to generate a near-global DEM of the Earth using radar interferometry. It was a primary component of the payload on space shuttle _Endeavour_ during its STS-99 mission, which was launched on February 11, 2000, and flew for 11 days. In addition to Terra Advanced Spaceborne Thermal and Reflection Radiometer (ASTER) Global Digital Elevation Model (GDEM) Version 2 data, NASADEM also relied on Ice, Cloud, and Land Elevation Satellite (ICESat) Geoscience Laser Altimeter System (GLAS) ground control points of its lidar shots to improve surface elevation measurements that led to improved geolocation accuracy. Other reprocessing improvements include the conversion to geoid reference and the use of GDEMs and Advanced Land Observing Satellite Panchromatic Remote-sensing Instrument for Stereo Mapping (PRISM) AW3D30 DEM, and interpolation for void filling. NASADEM are distributed in 1 degree latitude by 1 degree longitude tiles and consist of all land between 60° N and 56° S latitude. This accounts for about 80% of Earth's total landmass. NASADEM_SHHP data product layers include SRTM-only floating-point DEM and height error. A low-resolution browse image showing the SRTM-only elevation is also available for each NASADEM_SHHP granule.

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of the NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) version SRTM, which includes the global 1 arc second (~30 meter) product. NASA Shuttle Radar Topography Mission (SRTM) datasets result from a collaborative effort by the National Aeronautics and Space Administration (NASA) and the National Geospatial-Intelligence Agency (NGA - previously known as the National Imagery and Mapping Agency, or NIMA), as well as the participation of the German and Italian space agencies. The purpose of SRTM was to generate a near-global digital elevation model (DEM) of the Earth using radar interferometry. SRTM was a primary component of the payload on the Space Shuttle Endeavour during its STS-99 mission. Endeavour launched February 11, 2000 and flew for 11 days. SRTM collected data in swaths, which extend from ~30 degrees off-nadir to ~58 degrees off-nadir from an altitude of 233 kilometers (km). These swaths are ~225 km wide, and consisted of all land between 60° N and 56° S latitude. This accounts for about 80% of Earth's total landmass. Each SRTMGL1 data tile contains a mosaic and blending of elevations generated by averaging all "data takes" that fall within that tile. These elevation files use the extension ".HGT", meaning height (such as N37W105.SRTMGL1.HGT). The primary goal of creating the Version 3 data was to eliminate voids that were present in earlier versions of SRTM data. In areas with limited data, existing topographical data were used to supplement the SRTM data to fill the voids. The source of each elevation pixel is identified in the corresponding SRTMGL1N product (such as N37W105.SRTMGL1N.NUM). The global 1 arc second SRTM product is also available in NetCDF4 format as the SRTMGL1_NC dataset with the source of each elevation pixel in the corresponding SRTMGL1_NUMNC product. Known Issues * Known issues in the NASA SRTM are described in the following publication: * Rodriguez, E., C. S. Morris, and J. E. Belz (2006), A global assessment of the SRTM performance, Photogramm. Eng. Remote Sens., 72, 249–260. https://doi.org/10.14358/PERS.72.3.249

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) SRTM, which includes the global 3 arc second (~90 meter) product. The 3 arc second data was derived from the 1 arc second using averaging methods. (See Figure 3 in the User Guide) The NASA SRTM data sets result from a collaborative effort by the National Aeronautics and Space Administration (NASA) and the National Geospatial-Intelligence Agency (NGA - previously known as the National Imagery and Mapping Agency, or NIMA), as well as the participation of the German and Italian space agencies. This collaboration aims to generate a near-global digital elevation model (DEM) of Earth using radar interferometry. SRTM was the primary (and virtually only) payload on the STS-99 mission of the Space Shuttle Endeavour, which launched February 11, 2000 and flew for 11 days. The SRTM swaths extended from ~30 degrees off-nadir to ~58 degrees off-nadir from an altitude of 233 kilometers (km), creating swaths ~225 km wide, and consisted of all land between 60° N and 56° S latitude to account for 80% of Earth's total landmass. The SRTMGL3 data were generated from SRTM1GL data that fall within that tile. These elevation files use the extension ".HGT", meaning height (such as N37W105.SRTMGL3.HGT). The primary goal of creating the Version 3 data was to eliminate gaps, or voids, that were present in earlier versions of SRTM data. In areas with limited data, existing topographical data were used to supplement the SRTM data to fill the voids. The source of each elevation pixel is identified in the corresponding SRTMGL3N product (such as N37W105.SRTMGL3N.NUM). The global 3 arc second SRTM product is also available in NetCDF4 format as the SRTMGL3_NC dataset with the source of each elevation pixel in the corresponding SRTMGL3_NUMNC product. Known Issues * Known issues in the NASA SRTM are described in the following publication: * Rodriguez, E., C. S. Morris, and J. E. Belz (2006), A global assessment of the SRTM performance, Photogramm. Eng. Remote Sens., 72, 249–260. https://doi.org/10.14358/PERS.72.3.249

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of the NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) Digital Elevation Model (DEM) version 1 (NASADEM_HGT) dataset, which provides global elevation data at 1 arc second spacing. NASADEM data products were derived from original telemetry data from the Shuttle Radar Topography Mission (SRTM), a collaboration between NASA and the National Geospatial-Intelligence Agency (NGA), as well as participation from the German and Italian space agencies. SRTM's primary focus was to generate a near-global DEM of the Earth using radar interferometry. It was a primary component of the payload on space shuttle _Endeavour_ during its STS-99 mission, which was launched on February 11, 2000, and flew for 11 days. In addition to Terra Advanced Spaceborne Thermal and Reflection Radiometer (ASTER) Global Digital Elevation Model (GDEM) Version 2 data, NASADEM also relied on Ice, Cloud, and Land Elevation Satellite (ICESat) Geoscience Laser Altimeter System (GLAS) ground control points of its lidar shots to improve surface elevation measurements that led to improved geolocation accuracy. Other reprocessing improvements include the conversion to geoid reference and the use of GDEMs and Advanced Land Observing Satellite Panchromatic Remote-sensing instrument for Stereo Mapping (PRISM) AW3D30 DEM, and interpolation for void filling. NASADEM are distributed in 1 degree latitude by 1 degree longitude tiles and consist of all land between 60° N and 56° S latitude. This accounts for about 80% of Earth's total landmass. NASADEM_HGT data product layers include DEM, number of scenes (NUM), and an updated SRTM water body dataset (water mask). The NUM layer indicates the number of scenes that were processed for each pixel and the source of the data. A low-resolution browse image showing elevation is also available for each NASADEM_HGT granule. The global 1 arc second NASADEM product is also available in NetCDF4 format as the NASADEM_NC dataset with the source of each elevation pixel in the corresponding NASADEM_NUMNC product.

The Terra Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) Global Digital Elevation Model (GDEM) Version 3 (ASTGTM) provides a global digital elevation model (DEM) of land areas on Earth at a spatial resolution of 1 arc second (approximately 30 meter horizontal posting at the equator). The development of the ASTER GDEM data products is a collaborative effort between National Aeronautics and Space Administration (NASA) and Japan's Ministry of Economy, Trade, and Industry (METI). The ASTER GDEM data products are created by the Sensor Information Laboratory Corporation (SILC) in Tokyo. The ASTER GDEM Version 3 data product was created from the automated processing of the entire ASTER Level 1A archive of scenes acquired between March 1, 2000, and November 30, 2013. Stereo correlation was used to produce over one million individual scene based ASTER DEMs, to which cloud masking was applied. All cloud screened DEMs and non-cloud screened DEMs were stacked. Residual bad values and outliers were removed. In areas with limited data stacking, several existing reference DEMs were used to supplement ASTER data to correct for residual anomalies. Selected data were averaged to create final pixel values before partitioning the data into 1 degree latitude by 1 degree longitude tiles with a one pixel overlap. To correct elevation values of water body surfaces, the ASTER Global Water Bodies Database (ASTWBD) Version 1 data product was also generated. The geographic coverage of the ASTER GDEM extends from 83° North to 83° South. Each tile is distributed in both a Cloud Optimized GeoTIFF (COG) and NetCDF4 format through NASA Earthdata Search. Data are projected on the 1984 World Geodetic System (WGS84)/1996 Earth Gravitational Model (EGM96) geoid. Each of the 22,912 tiles in the collection contain at least 0.01% land area. Provided in the ASTER GDEM product are layers for DEM and number of scenes (NUM). The NUM layer indicates the number of scenes that were processed for each pixel and the source of the data. While the ASTER GDEM Version 3 data products offer substantial improvements over Version 2, users are advised that the products still may contain anomalies and artifacts that will reduce its usability for certain applications. Known Issues * ASTER GDEM Version 3 tiles overlap by one pixel to the north, south, east, and west of the tile perimeter. In most cases the overlapping edge pixels have identical pixel values, but it is possible that in some instances values will differ. * ASTER GDEM Version 3 is considered to be void free except for Greenland and Antarctica. * Users are reminded that because there are known inaccuracies and artifacts in the dataset, to use the product with awareness of these limitations. The data are provided "as is" and neither NASA nor METI/Earth Resources Satellite Data Analysis Center (ERSDAC) will be responsible for any damages resulting from use of the data.

Land area below 5m is the percentage of total land where the elevation is 5 meters or less.

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) SRTM, which includes the global 1 arc second (~30 meter) swath (raw) image data product. (See User Guide Section 2.2.1) The SRTM swath image data set consists of radar image files containing brightness values, as well as quality assurance (incidence angle) files for each of four overlapping sub-swaths that passes through a 1 degree by 1 degree tile. Data from each sub-swath is included as a separate file. Some files may contain only partial data; however, every image pixel acquired by SRTM is included in this data set. The NASA SRTM data sets result from a collaborative effort by the National Aeronautics and Space Administration (NASA) and the National Geospatial-Intelligence Agency (NGA - previously known as the National Imagery and Mapping Agency, or NIMA), as well as the participation of the German and Italian space agencies. This collaboration aims to generate a near-global digital elevation model (DEM) of Earth using radar interferometry. SRTM was the primary (and virtually only) payload on the STS-99 mission of the Space Shuttle Endeavour, which launched February 11, 2000 and flew for 11 days. The SRTM swaths extended from ~30 degrees off-nadir to ~58 degrees off-nadir from an altitude of 233 kilometers (km), creating swaths ~225 km wide, and consisted of all land between 60° N and 56° S latitude to account for 80% of Earth's total landmass. Known Issues * Known issues in the NASA SRTM are described in the following publication: * Rodriguez, E., C. S. Morris, and J. E. Belz (2006), A global assessment of the SRTM performance, Photogramm. Eng. Remote Sens., 72, 249–260. https://doi.org/10.14358/PERS.72.3.249

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) SRTM, which includes the global 3 arc second (~90 meter) product. The 3 arc second data was derived from the 1 arc second using averaging methods. (See Figure 3 in the User Guide) The NASA SRTM data sets result from a collaborative effort by the National Aeronautics and Space Administration (NASA) and the National Geospatial-Intelligence Agency (NGA - previously known as the National Imagery and Mapping Agency, or NIMA), as well as the participation of the German and Italian space agencies. This collaboration aims to generate a near-global digital elevation model (DEM) of Earth using radar interferometry. SRTM was the primary (and virtually only) payload on the STS-99 mission of the Space Shuttle Endeavour, which launched February 11, 2000 and flew for 11 days. The SRTM swaths extended from ~30 degrees off-nadir to ~58 degrees off-nadir from an altitude of 233 kilometers (km), creating swaths ~225 km wide, and consisted of all land between 60° N and 56° S latitude to account for 80% of Earth's total landmass. The SRTMGL3 data were generated from SRTM1GL data that fall within that tile. These elevation files use the extension ".HGT", meaning height (such as N37W105.SRTMGL3.HGT). The primary goal of creating the Version 3 data was to eliminate gaps, or voids, that were present in earlier versions of SRTM data. In areas with limited data, existing topographical data were used to supplement the SRTM data to fill the voids. The source of each elevation pixel is identified in the corresponding SRTMGL3N product (such as N37W105.SRTMGL3N.NUM). The global 3 arc second SRTM product is also available in NetCDF4 format as the SRTMGL3_NC dataset with the source of each elevation pixel in the corresponding SRTMGL3_NUMNC product. Known Issues * Known issues in the NASA SRTM are described in the following publication: * Rodriguez, E., C. S. Morris, and J. E. Belz (2006), A global assessment of the SRTM performance, Photogramm. Eng. Remote Sens., 72, 249–260. https://doi.org/10.14358/PERS.72.3.249

Level 1T is precision terrain correction by incorporating ground control points from the GLS2005 dataset. Scenes with sufficient ground control data and satisfactory RMS error are processed to Level 1T.

The Terra Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) Global Water Bodies Database (ASTWBD) Version 1 data product provides global coverage of water bodies larger than 0.2 square kilometers at a spatial resolution of 1 arc second (approximately 30 meters) at the equator, along with associated elevation information. The ASTWBD data product was created in conjunction with the ASTER Global Digital Elevation Model (ASTER GDEM) Version 3 data product by the Sensor Information Laboratory Corporation (SILC) in Tokyo. The ASTER GDEM Version 3 data product was generated using ASTER Level 1A scenes acquired between March 1, 2000, and November 30, 2013. The ASTWBD data product was then generated to correct elevation values of water body surfaces. To generate the ASTWBD data product, water bodies were separated from land areas and then classified into three categories: ocean, river, or lake. Oceans and lakes have a flattened, constant elevation value. The effects of sea ice were manually removed from areas classified as oceans to better delineate ocean shorelines in high latitude areas. For lake water bodies, the elevation for each lake was calculated from the perimeter elevation data using the mosaic image that covers the entire area of the lake. Rivers presented a unique challenge given that their elevations gradually step down from upstream to downstream; therefore, visual inspection and other manual detection methods were required. The geographic coverage of the ASTWBD extends from 83°N to 83°S. Each tile is distributed in GeoTIFF format and referenced to the 1984 World Geodetic System (WGS84)/1996 Earth Gravitational Model (EGM96) geoid. Each data product is provided as a zipped file that contains an attribute file with the water body classification information and a DEM file, which provides elevation information in meters.

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) Digital Elevation Model (DEM) version 1 (NASADEM_SIM) dataset, which provides global Shuttle Radar Topography Mission (SRTM) image mosaic data at 1 arc second spacing. NASADEM data products were derived from original telemetry data from the Shuttle Radar Topography Mission (SRTM), a collaboration between NASA and the National Geospatial-Intelligence Agency (NGA), as well as participation from the German and Italian space agencies. SRTM's primary focus was to generate a near-global DEM of the Earth using radar interferometry. It was a primary component of the payload on space shuttle _Endeavour_ during its STS-99 mission, which was launched on February 11, 2000, and flew for 11 days. In addition to Terra Advanced Spaceborne Thermal and Reflection Radiometer (ASTER) Global Digital Elevation Model (GDEM) Version 2 data, NASADEM also relied on Ice, Cloud, and Land Elevation Satellite (ICESat) Geoscience Laser Altimeter System (GLAS) ground control points of its lidar shots to improve surface elevation measurements that led to improved geolocation accuracy. Other reprocessing improvements include the conversion to geoid reference and the use of GDEMs and Advanced Land Observing Satellite Panchromatic Remote-sensing Instrument for Stereo Mapping (PRISM) AW3D30 DEM, and interpolation for void filling. NASADEM are distributed in 1 degree latitude by 1 degree longitude tiles and consist of all land between 60° N and 56° S latitude. This accounts for about 80% of Earth's total landmass. NASADEM_SIM data product layers include radar combined images and a NUM file associated with combined images. A low-resolution browse image showing the SRTM image mosaic elevation is also available for each NASADEM_SIM granule.

The Global Ecosystem Dynamics Investigation (GEDI) mission aims to characterize ecosystem structure and dynamics to enable radically improved quantification and understanding of the Earth’s carbon cycle and biodiversity. The GEDI instrument produces high resolution laser ranging observations of the 3-dimensional structure of the Earth. GEDI is attached to the International Space Station (ISS) and collects data globally between 51.6° N and 51.6° S latitudes at the highest resolution and densest sampling of any light detection and ranging (lidar) instrument in orbit to date. Each GEDI Version 3 granule encompasses one-fourth of an ISS orbit and includes georeferenced metadata to allow for spatial querying and subsetting. The GEDI instrument was removed from the ISS and placed into storage on March 17, 2023. No data were acquired during the hibernation period from March 17, 2023, to April 24, 2024. GEDI was re-instated on the ISS and resumed operations as of April 26, 2024. The GEDI Level 2A Geolocated Elevation and Height Metrics product (GEDI02_A) provides waveform interpretation and extracted products from each GEDI01_B received waveform, including ground elevation, canopy top height, and relative height (RH) metrics. The methodology for generating the GEDI02_A product datasets is adapted from the Land, Vegetation, and Ice Sensor (LVIS) algorithm. The GEDI02_A product is provided in HDF5 format and has a spatial resolution (average footprint) of 25 meters. The GEDI02_A data product contains 417 layers/variables for each of the eight beams, including ground elevation, canopy top height, relative return energy metrics (e.g., canopy vertical structure), and many other interpreted products from the return waveforms. Additional information for the layers can be found in the GEDI Level 2A Dictionary. Known Issues * Data acquisition gaps: GEDI data acquisitions were suspended on December 19, 2019 (2019 Day 353) and resumed on January 8, 2020 (2020 Day 8). * Known Issues: Section 8 of the User Guide provides additional information on known issues.

The Global Ecosystem Dynamics Investigation (GEDI) mission aims to characterize ecosystem structure and dynamics to enable radically improved quantification and understanding of the Earth’s carbon cycle and biodiversity. The GEDI instrument produces high resolution laser ranging observations of the 3-dimensional structure of the Earth. GEDI is attached to the International Space Station (ISS) and collects data globally between 51.6° N and 51.6° S latitudes at the highest resolution and densest sampling of any light detection and ranging (lidar) instrument in orbit to date. Each GEDI Version 2 granule encompasses one-fourth of an ISS orbit and includes georeferenced metadata to allow for spatial querying and subsetting. The GEDI instrument was removed from the ISS and placed into storage on March 17, 2023. No data were acquired during the hibernation period from March 17, 2023, to April 24, 2024. GEDI has since been reinstalled on the ISS and resumed operations as of April 26, 2024. The purpose of the GEDI Level 2A Geolocated Elevation and Height Metrics product (GEDI02_A) is to provide waveform interpretation and extracted products from each GEDI01_B received waveform, including ground elevation, canopy top height, and relative height (RH) metrics. The methodology for generating the GEDI02_A product datasets is adapted from the Land, Vegetation, and Ice Sensor (LVIS) algorithm. The GEDI02_A product is provided in HDF5 format and has a spatial resolution (average footprint) of 25 meters. The GEDI02_A data product contains 548 layers for each of the eight beams, including ground elevation, canopy top height, relative return energy metrics (e.g., canopy vertical structure), and many other interpreted products from the return waveforms. Additional information for the layers can be found in the GEDI Level 2A Dictionary. Known Issues * Data acquisition gaps: GEDI data acquisitions were suspended on December 19, 2019 (2019 Day 353) and resumed on January 8, 2020 (2020 Day 8). * Incorrect Reference Ground Track (RGT) number in the filename for select GEDI files: GEDI Science Data Products for six orbits on August 7, 2020, and November 12, 2021, had the incorrect RGT number in the filename. There is no impact to the science data, but users should reference this document for the correct RGT numbers. * Known Issues: Section 8 of the User Guide provides additional information on known issues.

The Global Ecosystem Dynamics Investigation (GEDI) mission aims to characterize ecosystem structure and dynamics to enable radically improved quantification and understanding of the Earth’s carbon cycle and biodiversity. The GEDI instrument produces high resolution laser ranging observations of the 3-dimensional structure of the Earth. GEDI is attached to the International Space Station (ISS) and collects data globally between 51.6° N and 51.6° S latitudes at the highest resolution and densest sampling of any light detection and ranging (lidar) instrument in orbit to date. Each GEDI Version 2 granule encompasses one-fourth of an ISS orbit and includes georeferenced metadata to allow for spatial querying and subsetting. The GEDI instrument was removed from the ISS and placed into storage on March 17, 2023. No data were acquired during the hibernation period from March 17, 2023, to April 24, 2024. GEDI has since been reinstalled on the ISS and resumed operations as of April 26, 2024. The GEDI Level 1B Geolocated Waveforms product (GEDI01_B) provides geolocated corrected and smoothed waveforms, geolocation parameters, and geophysical corrections for each laser shot for all eight GEDI beams. GEDI01_B data are created by geolocating the GEDI01_A raw waveform data. The GEDI01_B product is provided in HDF5 format and has a spatial resolution (average footprint) of 25 meters. The GEDI01_B data product contains 87 layers for each of the eight beams including the geolocated corrected and smoothed waveform datasets and parameters and the accompanying ancillary, geolocation, and geophysical correction. Additional information can be found in the GEDI L1B Product Data Dictionary. Known Issues * Data acquisition gaps: GEDI data acquisitions were suspended on December 19, 2019 (2019 Day 353) and resumed on January 8, 2020 (2020 Day 8). * Incorrect Reference Ground Track (RGT) number in the filename for select GEDI files: GEDI Science Data Products for six orbits on August 7, 2020, and November 12, 2021, had the incorrect RGT number in the filename. There is no impact to the science data, but users should reference this document for the correct RGT numbers. * Known Issues: Section 8 of the User Guide provides additional information on known issues.

The NOAA-21 Visible Infrared Imaging Radiometer Suite (VIIRS) Water Reservoir 8-day Level 3 (L3) Global (VJ228C2) Version 2 product provides current data for 151 man-made reservoirs and 13 regulated natural lakes for a total of 164 reservoirs. The VJ228C2 data product provides an 8-day time series of surface area, elevation, and water storage. Datasets are combined with pre-established Area-Elevation (A-E) curves and image classifications of near-infrared (NIR) reflectance from the surface reflectance product acquired by the VIIRS satellite (VJ209H1). The VJ228C2 data product consists of a single variable with information about the reservoir identifier, dam location (longitude and latitude), reservoir surface area, elevation, and water storage capacity. Known Issues * Water occurrence images generally show smaller surface area dynamics in high latitude regions, creating pixels with low occurrence values that have relatively large uncertainties. In addition, the quality of raw water area classification can be affected by lake ice coverage typically creating an overestimation of surface area in the enhancement algorithm. This issue will be addressed in a future release of the enhancement algorithm. For additional information about known issues, refer to Section 4 in the User Guide.

Urban land area below 5m is the total urban land area in square kilometers where the elevation is 5 meters or less.

The Land Processes Distributed Active Archive Center (LP DAAC) is responsible for the archive and distribution of NASA Making Earth System Data Records for Use in Research Environments (MEaSUREs) Digital Elevation Model (DEM) version 1 (NASADEM_SC) dataset, which provides global slope and curvature elevation data at 1 arc second spacing. NASADEM data products were derived from original telemetry data from the Shuttle Radar Topography Mission (SRTM), a collaboration between NASA and the National Geospatial-Intelligence Agency (NGA), as well as participation from the German and Italian space agencies. SRTM's primary focus was to generate a near-global DEM of the Earth using radar interferometry. It was a primary component of the payload on space shuttle _Endeavour_ during its STS-99 mission, which was launched on February 11, 2000, and flew for 11 days. In addition to Terra Advanced Spaceborne Thermal and Reflection Radiometer (ASTER) Global Digital Elevation Model (GDEM) Version 2 data, NASADEM also relied on Ice, Cloud, and Land Elevation Satellite (ICESat) Geoscience Laser Altimeter System (GLAS) ground control points of its lidar shots to improve surface elevation measurements that led to improved geolocation accuracy. Other reprocessing improvements include the conversion to geoid reference and the use of GDEMs and Advanced Land Observing Satellite Panchromatic Remote-sensing instrument for Stereo Mapping (PRISM) AW3D30 DEM, and interpolation for void filling. NASADEM are distributed in 1 degree latitude by 1 degree longitude tiles and consist of all land between 60° N and 56° S latitude. This accounts for about 80% of Earth's total landmass. NASADEM_SC data product layers include slope, aspect angle, profile curvature, plan curvature, and an updated SRTM water body dataset (water mask). A low-resolution browse image showing slope is also available for each NASADEM_SC granule.

Urban land area below 5m is the percentage of total land where the urban land elevation is 5 meters or less.

The Terra Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) Digital Elevation Model (AST14DEM) product is generated using bands 3N (nadir-viewing) and 3B (backward-viewing) of an ASTER Level 1A image acquired by the Visible and Near Infrared (VNIR) sensor. The VNIR subsystem includes two independent telescope assemblies that facilitate the generation of stereoscopic data. The band 3 stereo pair is acquired in the spectral range of 0.78 and 0.86 microns with a base-to-height ratio of 0.6 and an intersection angle of 27.7 degrees. There is a time lag of approximately one minute between the acquisition of the nadir and backward images. For a better understanding, refer to the diagram depicting the along-track imaging geometry diagram of the ASTER VNIR nadir and backward-viewing sensors. Known Issues * Data acquisition gap: On November 28, 2024, one of Terra's power-transmitting shunt units failed. As a result, there was insufficient power to maintain functionality of the ASTER instrument. ASTER resumed acquisitions for the VNIR bands on January 18, 2025. Users should note the data gap in ASTER acquisitions from November 28, 2024, through January 16, 2025, for VNIR observations.
