RDCO Elevations LiDAR2018 (Image Server)

Overview This service presents a styled hillshade surface for the Regional District of Central Okanagan area. It visualizes shaded relief derived from a digital elevation model using blue and purple symbology, supporting map display and feature queries. Layers Hillshade - bidirectional - multicolor (blue/purple): a grouped hillshade display built from two raster views of the same elevation surface. Hillshade_DEM_RDCO - 360 - #660066: a shaded relief surface rendered in purple tones. Hillshade_DEM_RDCO - 270 - #0059B2: a shaded relief surface rendered in blue tones. Characteristics The service depicts terrain illumination and elevation form as a continuous surface, with each pixel representing hillshade intensity from the underlying elevation model. The layered styling supports visual interpretation of slopes, ridges, valleys, and landform texture. Image interpretation: This service contains shaded relief imagery that represents terrain intensity values across the covered area. It is well suited to cartographic display, terrain visualization, and comparison of relief patterns. Temporal summary: The service is static and presents a single terrain representation with no time-based changes. Geographic Coverage The map coverage spans the Regional District of Central Okanagan area in Web Mercator spatial reference. Use Cases This service supports terrain-rich basemaps, landscape visualization, and contextual mapping for planning, environmental review, and cartographic production.

OverviewThis image service provides 2023 orthophotography from the Orthoimagery Aerials2023 Eagle View mosaic dataset. It delivers RGB imagery as a three band, 8 bit raster service with 0.25 meter pixel size and bilinear resampling. The service covers a local area in spatial reference 2881 and is delivered as a managed image collection with catalog access. Raster PropertiesData type: RGB imagery Pixel type: U8 Band count: 3 Band values: Band 1, Band 2, Band 3 Pixel size: 0.25 x 0.25 Dataset format: AMD Compression: None Resampling method: Bilinear Value range: 0 to 255 for each band Mean values: 110.08, 109.55, 82.63 Standard deviations: 31.21, 26.24, 25.53 Histogram range: -0.5 to 255.5 for each band Raster functions: None and Eagle View Stretch Mosaic PropertiesThe service is built from a mosaic dataset and combines multiple raster items on the fly. It supports Catalog, Download, Image, and Metadata capabilities. Users can browse individual catalog items, review metadata, and access imagery for display and download. Supported mosaic methods include NorthWest, Center, LockRaster, ByAttribute, Nadir, Viewpoint, Seamline, and None. The service can composite up to 42 images at once. Catalog fields describe each raster item with metadata such as name, pixel size range, category, tag, group name, product name, center location, and z order. The category domain includes values such as Primary, Overview, Uploaded, and Custom. Geographic CoverageThe imagery covers a local area of approximately 0.43 degrees in latitude and longitude extent, centered in northeastern Florida. Extent:xmin: -81.52329610896626 ymin: 29.256706249842132 xmax: -81.09774534379683 ymax: 29.683933726633093 Spatial reference: 2881 Use CasesThis service supports imagery viewing, catalog browsing, metadata review, and image download workflows. It allows users to copy data and run analysis, and it supports standardized catalog queries with statistics, SQL expressions, ordering, pagination, and distinct queries. Downloads are limited to 20 images per request with a 2048 MB size limit. The service does not provide mensuration capabilities.

The Earth Surface Mineral Dust Source Investigation (EMIT) instrument measures surface mineralogy, targeting the Earth’s arid dust source regions. EMIT is installed on the International Space Station (ISS) and uses imaging spectroscopy to take mineralogical measurements of sunlit regions of interest between 52° N latitude and 52° S latitude. An interactive map showing the regions being investigated, current and forecasted data coverage, and additional data resources can be found on the VSWIR Imaging Spectroscopy Interface for Open Science (VISIONS) EMIT Open Data Portal. The EMIT Level 1B At-Sensor Calibrated Radiance and Geolocation (EMITL1BRAD) Version 1 data product provides at-sensor calibrated radiance values along with observation data in a spatially raw, non-orthocorrected format. Each EMITL1BRAD granule consists of two Network Common Data Format 4 (NetCDF4) files at a spatial resolution of 60 meters (m): Radiance (EMIT_L1B_RAD) and Observation (EMIT_L1B_OBS). The Radiance file contains the at-sensor radiance measurements of 285 bands with a spectral range of 381-2493 nanometers (nm) and with a spectral resolution of ~7.5 nm, which are held within a single science dataset layer (SDS). The Observation file contains viewing and solar geometries, timing, topographic, and other information related to the observation. Each NetCDF4 file holds a location group containing geometric lookup tables (GLT), which are orthorectified images that provide relative x and y reference locations from the raw scene to allow for projection of the data. Along with the GLT layers, the files also contain latitude, longitude, and elevation layers. The latitude and longitude coordinates are presented using the World Geodetic System (WGS84) ellipsoid. The elevation data was obtained from Shuttle Radar Topography Mission v3 (SRTM v3) data and resampled to EMIT’s spatial resolution. Each granule is approximately 75 kilometers (km) by 75 km, nominal at the equator, with some granules at the end of an orbit segment reaching 150 km in length. Known Issues * Data acquisition gap: From September 13, 2022, through January 6, 2023, a power issue outside of EMIT caused a pause in operations. Due to this shutdown, no data were acquired during that timeframe.

Goddard’s LiDAR, Hyperspectral, and Thermal Imagery (G-LiHT) mission is a portable, airborne imaging system that aims to simultaneously map the composition, structure, and function of terrestrial ecosystems. G-LiHT primarily focuses on a broad diversity of forest communities and ecoregions in North America, mapping aerial swaths over the Conterminous United States (CONUS), Alaska, Puerto Rico, and Mexico. The purpose of G-LiHT’s Digital Surface Model data product (GLDSMT) is to provide LiDAR-derived visualizations of elevation above bare earth. GLDSMT data is offered in multiple formats, including Digital Surface Model, Mean, Aspect, Rugosity, and Slope. GLDSMT data are processed as multiple raster data products (GeoTIFFs) at a nominal 1 meter spatial resolution over locally defined areas. A low resolution browse is also provided showing the digital surface model with a color map applied in PNG format.

The Terra Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) Global Digital Elevation Model (GDEM) Version 3 (ASTGTM) provides a global digital elevation model (DEM) of land areas on Earth at a spatial resolution of 1 arc second (approximately 30 meter horizontal posting at the equator). The development of the ASTER GDEM data products is a collaborative effort between National Aeronautics and Space Administration (NASA) and Japan's Ministry of Economy, Trade, and Industry (METI). The ASTER GDEM data products are created by the Sensor Information Laboratory Corporation (SILC) in Tokyo. The ASTER GDEM Version 3 data product was created from the automated processing of the entire ASTER Level 1A archive of scenes acquired between March 1, 2000, and November 30, 2013. Stereo correlation was used to produce over one million individual scene based ASTER DEMs, to which cloud masking was applied. All cloud screened DEMs and non-cloud screened DEMs were stacked. Residual bad values and outliers were removed. In areas with limited data stacking, several existing reference DEMs were used to supplement ASTER data to correct for residual anomalies. Selected data were averaged to create final pixel values before partitioning the data into 1 degree latitude by 1 degree longitude tiles with a one pixel overlap. To correct elevation values of water body surfaces, the ASTER Global Water Bodies Database (ASTWBD) Version 1 data product was also generated. The geographic coverage of the ASTER GDEM extends from 83° North to 83° South. Each tile is distributed in both a Cloud Optimized GeoTIFF (COG) and NetCDF4 format through NASA Earthdata Search. Data are projected on the 1984 World Geodetic System (WGS84)/1996 Earth Gravitational Model (EGM96) geoid. Each of the 22,912 tiles in the collection contain at least 0.01% land area. Provided in the ASTER GDEM product are layers for DEM and number of scenes (NUM). The NUM layer indicates the number of scenes that were processed for each pixel and the source of the data. While the ASTER GDEM Version 3 data products offer substantial improvements over Version 2, users are advised that the products still may contain anomalies and artifacts that will reduce its usability for certain applications. Known Issues * ASTER GDEM Version 3 tiles overlap by one pixel to the north, south, east, and west of the tile perimeter. In most cases the overlapping edge pixels have identical pixel values, but it is possible that in some instances values will differ. * ASTER GDEM Version 3 is considered to be void free except for Greenland and Antarctica. * Users are reminded that because there are known inaccuracies and artifacts in the dataset, to use the product with awareness of these limitations. The data are provided "as is" and neither NASA nor METI/Earth Resources Satellite Data Analysis Center (ERSDAC) will be responsible for any damages resulting from use of the data.

The Terra Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) Global Digital Elevation Model (GDEM) Version 3 (ASTGTM) provides a global digital elevation model (DEM) of land areas on Earth at a spatial resolution of 1 arc second (approximately 30 meter horizontal posting at the equator). The development of the ASTER GDEM data products is a collaborative effort between National Aeronautics and Space Administration (NASA) and Japan's Ministry of Economy, Trade, and Industry (METI). The ASTER GDEM data products are created by the Sensor Information Laboratory Corporation (SILC) in Tokyo. The ASTER GDEM Version 3 data product was created from the automated processing of the entire ASTER Level 1A archive of scenes acquired between March 1, 2000, and November 30, 2013. Stereo correlation was used to produce over one million individual scene based ASTER DEMs, to which cloud masking was applied. All cloud screened DEMs and non-cloud screened DEMs were stacked. Residual bad values and outliers were removed. In areas with limited data stacking, several existing reference DEMs were used to supplement ASTER data to correct for residual anomalies. Selected data were averaged to create final pixel values before partitioning the data into 1 degree latitude by 1 degree longitude tiles with a one pixel overlap. To correct elevation values of water body surfaces, the ASTER Global Water Bodies Database (ASTWBD) Version 1 data product was also generated. The geographic coverage of the ASTER GDEM extends from 83° North to 83° South. Each tile is distributed in both a Cloud Optimized GeoTIFF (COG) and NetCDF4 format through NASA Earthdata Search. Data are projected on the 1984 World Geodetic System (WGS84)/1996 Earth Gravitational Model (EGM96) geoid. Each of the 22,912 tiles in the collection contain at least 0.01% land area. Provided in the ASTER GDEM product are layers for DEM and number of scenes (NUM). The NUM layer indicates the number of scenes that were processed for each pixel and the source of the data. While the ASTER GDEM Version 3 data products offer substantial improvements over Version 2, users are advised that the products still may contain anomalies and artifacts that will reduce its usability for certain applications. Known Issues * ASTER GDEM Version 3 tiles overlap by one pixel to the north, south, east, and west of the tile perimeter. In most cases the overlapping edge pixels have identical pixel values, but it is possible that in some instances values will differ. * ASTER GDEM Version 3 is considered to be void free except for Greenland and Antarctica. * Users are reminded that because there are known inaccuracies and artifacts in the dataset, to use the product with awareness of these limitations. The data are provided "as is" and neither NASA nor METI/Earth Resources Satellite Data Analysis Center (ERSDAC) will be responsible for any damages resulting from use of the data.
